Series 5 *425 (Flow Rate 1.05-6.6 GPM)


  • Starting at

Series 5 is a flow regulator with double manifold inlet/return and temperature control. It is the most compact size available in the market. Solenoid valves are optional and can be installed on each return circuit from the mold.

Technical Data:

  • Individual circuit regulation valves to eliminate flow fluctuations
  • Internal composite floats along with external, adjustable sights glass tube ring
  • Methacrylate with brass- aluminum components
  • Mold connections with 3/8"G brass and hose fittings (10/13 mm)
  • Maximum working pressure 20 bar
  • Maximum working temperature 90° C
  • Two manifolds

*425 model comes with brass floats.
